Конфигурация на ModSecurity с Nginx уеб сървър

/

modsec

Как да конфигурираме ModSecurity с Nginx уеб сървър ?

Nginx уебсървър

ModSecurity е Web Application Firewall ( WAF ) който може да предпази уеб сървисите ( съответно и всички уебсайтове на този хост ) от недоброжелателни хора или ботове в мрежата.

Списък с едни от най-популярните уеб атаки от които може да ни предпази ModSecurity конфигуриран съвместно с OWASP Core Rule Set .

  1. SQL Injection (SQLi)
  2. Cross Site Scripting (XSS)
  3. Local File Inclusion (LFI)
  4. Remote File Inclusion (RFI)
  5. Remote Code Execution (RCE)
  6. PHP Code Injection
  7. HTTP Protocol Violations
  8. HTTPoxy
  9. Shellshock
  10. Session Fixation
  11. Scanner Detection

В тази статия ще разгледаме как да компилираме и инсталираме ModSecurity за работа с един от най-използваните уеб сървъри в света Nginx.

Операционната система за сървър която използваме е CentOS 8.1 .

CentOS 8.1 уеб сървър

Първо, нека да инсталираме основните зависимости от пакетният мениджър.

dnf -y install wget tar
dnf -y install gcc pcre pcre-devel openssl openssl-devel libicu libicu-devel bzip2-devel bzip2-libs cyrus-sasl-devel
dnf -y groupinstall „Development Tools“

Сваляме, компилираме и инсталираме LibModSecurity

git clone –depth 1 -b v3/master –single-branch https://github.com/SpiderLabs/ModSecurity
cd ModSecurity
git submodule init
git submodule update
./build.sh
./configure
make
make install

Компилиране и инсталиране на ModSecurity за работа с Nginx .

Първо, трябва да свалиме ModSecurity nginx-connector модула.

git clone –depth 1 https://github.com/SpiderLabs/ModSecurity-nginx.git

Сваляме и компилираме Nginx с ModSecurity модула.

Трябва предварително да създадем потребител с който ще работи Nginx.

wget https://nginx.org/download/nginx-1.17.8.tar.gz
tar -xf nginx-1.17.8.tar.gz

./configure \
–user=nginx \
–group=nginx \
–prefix=/etc/nginx \
–sbin-path=/usr/sbin/nginx \
–conf-path=/etc/nginx/nginx.conf \
–pid-path=/var/run/nginx.pid \
–lock-path=/var/run/nginx.lock \
–error-log-path=/var/log/nginx/error.log \
–http-log-path=/var/log/nginx/access.log \
–with-http_gzip_static_module \
–with-http_stub_status_module \
–with-http_ssl_module \
–with-pcre \
–with-file-aio \
–with-http_realip_module \
–with-compat –add-dynamic-module=../ModSecurity-nginx/

make
make install

След това трябва да заредим в /etc/nginx/nginx.conf ModSecurity модула (най-отгоре в файла).

load_module modules/ngx_http_modsecurity_module.so;

Конфигурираме и инсталираме OWASP Core Rule Set / CSR / версия 3.0.2 актуалната към момента .

mkdir -p /etc/nginx/modsec/
wget https://github.com/SpiderLabs/owasp-modsecurity-crs/archive/v3.0.2.tar.gz

wget -P /etc/nginx/modsec/ https://raw.githubusercontent.com/SpiderLabs/ModSecurity/v3/master/modsecurity.conf-recommended
mv /etc/nginx/modsec/modsecurity.conf-recommended /etc/nginx/modsec/modsecurity.conf
sed -i ‘s/SecRuleEngine DetectionOnly/SecRuleEngine On/’ /etc/nginx/modsec/modsecurity.conf
tar -xzvf v3.0.2.tar.gz
sudo mv owasp-modsecurity-crs-3.0.2 /usr/local
cd /usr/local/owasp-modsecurity-crs-3.0.2
sudo cp crs-setup.conf.example crs-setup.conf
cp REQUEST-900-EXCLUSION-RULES-BEFORE-CRS.conf.example REQUEST-900-EXCLUSION-RULES-BEFORE-CRS.conf
cp RESPONSE-999-EXCLUSION-RULES-AFTER-CRS.conf.example RESPONSE-999-EXCLUSION-RULES-AFTER-CRS.conf
cp /usr/src/ModSecurity/unicode.mapping /etc/nginx/modsec/

Зареждаме всички CSR правила.

vim /etc/nginx/modsec/main.conf

# Include the recommended configuration
Include /etc/nginx/modsec/modsecurity.conf
# OWASP CRS v3 rules
Include /usr/local/owasp-modsecurity-crs-3.0.2/crs-setup.conf
Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/REQUEST-900-EXCLUSION-RULES-BEFORE-CRS.conf
Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/REQUEST-901-INITIALIZATION.conf
Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/REQUEST-905-COMMON-EXCEPTIONS.conf
#Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/REQUEST-910-IP-REPUTATION.conf
Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/REQUEST-911-METHOD-ENFORCEMENT.conf
Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/REQUEST-912-DOS-PROTECTION.conf
Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/REQUEST-913-SCANNER-DETECTION.conf
Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/REQUEST-920-PROTOCOL-ENFORCEMENT.conf
Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/REQUEST-921-PROTOCOL-ATTACK.conf
Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/REQUEST-930-APPLICATION-ATTACK-LFI.conf
Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/REQUEST-931-APPLICATION-ATTACK-RFI.conf
Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/REQUEST-932-APPLICATION-ATTACK-RCE.conf
Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/REQUEST-933-APPLICATION-ATTACK-PHP.conf
Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/REQUEST-941-APPLICATION-ATTACK-XSS.conf
Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/REQUEST-942-APPLICATION-ATTACK-SQLI.conf
Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/REQUEST-943-APPLICATION-ATTACK-SESSION-FIXATION.conf
Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/REQUEST-949-BLOCKING-EVALUATION.conf
Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/RESPONSE-950-DATA-LEAKAGES.conf
Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/RESPONSE-951-DATA-LEAKAGES-SQL.conf
Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/RESPONSE-952-DATA-LEAKAGES-JAVA.conf
Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/RESPONSE-953-DATA-LEAKAGES-PHP.conf
Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/RESPONSE-954-DATA-LEAKAGES-IIS.conf
Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/RESPONSE-959-BLOCKING-EVALUATION.conf
Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/RESPONSE-980-CORRELATION.conf
Include /usr/local/owasp-modsecurity-crs-3.0.2/rules/RESPONSE-999-EXCLUSION-RULES-AFTER-CRS.conf

Конфигурираме Nginx да използва модула.

vim /etc/nginx/nginx.conf

В server { } блока добавяме:

modsecurity on;
modsecurity_rules_file /etc/nginx/modsec/main.conf;
За финал, нека създадем systemd service файл за Nginx.
vim /etc/systemd/system/nginx.service

[Unit] Description=The nginx server
After=network.target remote-fs.target nss-lookup.target

[Service] Type=forking
PIDFile=/run/nginx.pid
ExecStartPre=/usr/bin/rm -f /run/nginx.pid
ExecStartPre=/usr/sbin/nginx -t
ExecStart=/usr/sbin/nginx
ExecReload=/bin/kill -s HUP $MAINPID
KillSignal=SIGQUIT
TimeoutStopSec=5
KillMode=mixed
PrivateTmp=true
[Install] WantedBy=multi-user.target

systemctl daemon-reload
systemctl start nginx
systemctl enable nginx
